36W Street Light Set Glass Model Regular – front view | Xera Tech 36W Street Light Set Glass Model – back view showing driver and heat sink | Xera Tech 36W IP66 Street Light Set – side profile | Xera Tech 36W Street Light Set specifications sheet – 36W 90V – 300V AC IP66 | Xera Tech
See it in action
Download 36W–100W Street Light Set – Glass Model datasheet (PDF)

Download complete technical datasheet including wattage, dimensions, IP rating, material specifications, lumen output, installation details and warranty information.

Available in Nashik, India

36W–100W Street Light Set – Glass Model

SL-GM-36-100 IP66 120° CRI ≥ 80

Short link: xeratech.in/products/SL-GM-36-100

4.5 | 23 reviews
₹4,200 ₹5,000 16% OFF

Excl. GST  |  Min. 2 units  |  In stock: 500 units

Select Wattage:
24W ₹2,800 24W ₹2,500 36W ₹4,200
Colour Temperature:
Cool White Natural White Warm White
Quantity

Min. 2 units

WhatsApp
2 Years Warranty Pan-India Delivery 7 days Returns ISO, BIS, NSIC, NABL & more Made in Nashik, India

Key Highlights

36W
Wattage
2 Years
Warranty
IP66
IP Rating
120°
Beam Angle
≥ 80
CRI
50,000 hr
LED Life
≥ 0.95
Power Factor
20,000g
Weight

Why Choose the 36W Street Light Set

💡
Up to 75% Energy Saving
Replaces a typical 150W halogen street light set while consuming only 36W, cutting running cost by up to 75%.
🌧️
IP66 Weatherproof
Completely dust-tight and protected against powerful water jets from any direction — built for India's monsoons, heat, and industrial environments.
🕐
50,000 hr LED Life
With 50,000 hr rated life and 90% LED efficiency, expect years of maintenance-free outdoor lighting.
⚡
Wide Voltage: 90V – 300V AC
Works on 90V – 300V AC — handles Indian grid fluctuations, load-shedding, and voltage surges without damage.
🏆
ISO, BIS, NSIC, NABL & more Certified
Carries ISO, BIS, NSIC, NABL, ZED, PWD, ERDA, GeM, NMC certification — accepted in government tenders, municipal projects, and industrial procurement.
🌡️
-20°C to 50°C Operating Range
Performs reliably from icy northern winters to scorching Rajasthan summers — no derating, no shutdown.

Electricity Saving Calculator

See how much you save by switching to the 36W LED Street Light Set from traditional HPSV (sodium vapour) lights.

₹0
Annual Saving
₹0
Monthly Saving
0 mo
Payback Period

Product Description

The 36W–100W Street Light Set – Glass Model is a 36W LED Street Light Set manufactured by Xera Tech in Nashik, Maharashtra. Designed for demanding outdoor and industrial environments, this IP66 street light set is built for long, dependable outdoor service — making it one of the most durable outdoor street light sets available in India.

Powered by 90% efficient LEDs with a rated life of 50,000 hr, this 36W outdoor street light set delivers a 120° beam angle and CRI of ≥ 80 — ensuring excellent colour rendering for streets, warehouses, facades, and industrial campuses. The Aluminium Die Cast housing provides structural rigidity and efficient heat sinking, critical for continuous-duty outdoor installations.

Operating on a wide input of 90V – 300V AC at 50Hz, with built-in 6kV surge protection and a power factor of ≥ 0.95, this IP66 street light set is purpose-engineered for Indian grid conditions — including rural areas with frequent voltage fluctuations and load-shedding. Operating temperature range: -20°C to 50°C.

Certified ISO, BIS, NSIC, NABL, ZED, PWD, ERDA, GeM, NMC, the 36W–100W Street Light Set – Glass Model is pre-qualified for government tenders, municipal infrastructure bids, and private industrial procurement across India. Applications include: Highways, Main Roads, Industrial Zones, Large Area Lighting, Municipal Roads, NHAI Roads, Commercial Zones.

As a leading LED street light set manufacturer in Nashik, Maharashtra, Xera Tech supplies this product pan-India with 2 Years manufacturer warranty and 7 days return policy (HSN: 9405 49 00). The Isolated driver also carries a 2 Years warranty, ensuring your total cost of ownership remains predictable over the fixture's lifetime.

Full Technical Specifications

Brand Xera Tech
SKU / Model SL-GM-36-100
Wattage 36W
LED Efficiency 90%
LED Life 50,000 hr
CRI ≥ 80
Beam Angle 120°
IP Rating IP66
Housing Aluminium Die Cast
Driver Type Isolated
Driver Efficiency 90%
Power Factor ≥ 0.95
Voltage Range 90V – 300V AC
Frequency 50Hz
Surge Protection 6kV
Operating Temp. -20°C to 50°C
Dimensions (H×W×D) 6000mm × 300mm × 300mm
Package Dims. 6200mm × 400mm × 400mm
Weight 20,000g
Mounting Pipe ID 76mm
Body Colour Customisable (PU Paint)
Colour Variants Cool White,Natural White,Warm White
Warranty 2 Years
Driver Life 2 Years
Application Highways, Main Roads, Industrial Zones, Large Area Lighting, Municipal Roads, NHAI Roads, Commercial Zones
Certifications ISO, BIS, NSIC, NABL, ZED, PWD, ERDA, GeM, NMC
Customer Segment Municipal Bodies, NHAI, PWD, Industrial Estates, Smart City Corporations, Government Tenders, Commercial Projects
Min. Order Qty 2 units
HSN Code 9405 49 00
Return Policy 7 days

Key Features

High Wattage 36W–100W AC Grid Powered Glass Model LED 6 Mtr GI Pole PU Paint Finish Swaging Pole (114>100>88>76>60) Bracket 500–1500mm Customisable Base Plate Included Foundation Bolts Included High Transparency Durability UV Protection Energy Efficiency Easy Maintenance

Certifications

ISO
BIS
NSIC
NABL
ZED
PWD
ERDA
GeM
NMC

Applications

Highways
Main Roads
Industrial Zones
Large Area Lighting
Municipal Roads
NHAI Roads
Commercial Zones

How to Install the 36W–100W Street Light Set – Glass Model

Complete installation guide for the 36W Street Light Set (Glass Model, Regular). Required supplies: 36W–100W LED Glass Model Luminaire (1 No), 6 Mtr GI Pole, Customisable Bracket, Base Plate, Foundation Bolts, Aluminium Armoured Cable, DP MCB, DWC Pipe, Earthing Pipe & Wire, Feeder Panel, FRP Box, MSB.

1
Fix the bracket
Secure the street light set bracket to the mounting surface (wall, pole, or structure) using M8 or M10 bolts. Ensure the surface can bear at least 20000g.
2
Route the wiring
Route 3-core (L, N, E) cable rated for 90V – 300V AC through the conduit to the junction point. Minimum wire gauge: 1.5 mm².
3
Connect terminals
Connect Live (L), Neutral (N) and Earth (E) to the corresponding terminals in the Isolated driver. The driver supports 90V – 300V AC at 50Hz.
4
Mount the fixture
Attach the 36W–100W Street Light Set – Glass Model to the bracket, tighten the locking knob, and adjust the tilt angle for desired beam direction (120° beam).
5
Test and verify
Power on via MCB/DP switch. Verify output brightness (CRI ≥ 80), check IP66 gaskets are sealed, and confirm 6kV surge protector LED is green.
Need professional installation in Nashik or nearby? +91-9607908423 | WhatsApp us

Frequently Asked Questions about 36W LED Street Light Set

The 36W–100W Street Light Set – Glass Model is a 36W LED Street Light Set with IP66 ingress protection, 120° beam angle, CRI ≥ 80, 50,000 hr LED life, and 36W 90% efficiency. It operates on 90V – 300V AC at 50Hz with 6kV surge protection.
The 36W–100W Street Light Set – Glass Model carries an IP66 rating. The first digit (6) means it is completely dust-tight. The second digit (6) means it is protected against powerful water jets from any direction. This suits outdoor Indian conditions including monsoons and industrial washdown areas.
LED street light sets use far less power than halogen, metal-halide or sodium-vapour fittings at similar lighting levels. See the running-cost answers below for 36W-specific figures. Actual savings depend on your tariff, burning hours and the lighting level your site needs. With 50,000 hr LED life, you also avoid frequent lamp replacements.
Yes. With IP66 protection, -20°C to 50°C operating range, and 6kV surge protection for grid fluctuations, it is purpose-built for Indian outdoor conditions. Applications include: Highways, Main Roads, Industrial Zones, Large Area Lighting, Municipal Roads, NHAI Roads, Commercial Zones.
It supports 90V – 300V AC at 50Hz, covering virtually all Indian grid conditions including rural areas with unstable supply. The power factor of ≥ 0.95 ensures minimal reactive current draw.
Xera Tech provides 2 Years manufacturer warranty on the light and 2 Years on the driver. For warranty claims, contact connect@xeratech.in or call +91-9607908423. Returns are accepted within 7 days of delivery. HSN code: 9405 49 00.
For a complete installation set: 36W–100W LED Glass Model Luminaire (1 No), 6 Mtr GI Pole, Customisable Bracket, Base Plate, Foundation Bolts, Aluminium Armoured Cable, DP MCB, DWC Pipe, Earthing Pipe & Wire, Feeder Panel, FRP Box, MSB. Mounting pipe inner diameter: 76mm.
Yes. Xera Tech offers dealer pricing, bulk discounts, and government tender pricing for orders above the minimum quantity of 2 units. Custom wattages, special colour temperatures, and project-specific configurations are available on request. Contact connect@xeratech.in or WhatsApp +91-9607908430 for a custom quote.
The 36W–100W Street Light Set – Glass Model is priced at ₹4,200 per unit excluding GST (MRP ₹5,000). With 18% GST the price is about ₹4,956.00 per unit. The minimum order quantity is 2 units and 500 units are listed in stock. Bulk, dealer and government-tender pricing is available on request.
Running dusk to dawn (about 12 hours a night), a 36W fixture uses roughly 158 units (kWh) a year. At ₹8 per unit that is about ₹1,261 a year, and at ₹10 per unit about ₹1,577. Your actual cost depends on your tariff and burning hours.
A 150W halogen fitting running 12 hours a night uses about 657 units a year (about ₹5,256 at ₹8 per unit). The 36W LED uses about 158 units (about ₹1,261), a saving of roughly ₹3,995 per fitting per year. Confirm that the LED gives the lighting level your site needs before replacing old fittings; Xera Tech can run a lux calculation at no cost.
The 36W–100W Street Light Set – Glass Model measures 6000mm × 300mm × 300mm (H × W × D) and weighs 20,000g. Mounting pipe inner diameter: 76mm. Housing: Aluminium Die Cast. Body colour: Customisable (PU Paint).
Listed certifications: ISO, BIS, NSIC, NABL, ZED, PWD, ERDA, GeM, NMC. Copies of certificates and test reports can be requested for tender or project submissions by writing to connect@xeratech.in or calling +91-9607908423.
Available in: Cool White,Natural White,Warm White. State the colour temperature you need when ordering and ask for the exact Kelvin rating on the datasheet.
The LED is rated for 50,000 hr, which is roughly 11 years at 12 hours of use a night. This is the rated LED life, not a warranty period. The product warranty is 2 Years and the driver warranty is 2 Years.
Yes. Xera Tech ships pan-India from Nashik, Maharashtra. Orders are normally dispatched within 1–2 working days and typically arrive in 3–7 days. Returns are accepted within 7 days of delivery.
Available wattages and per-unit prices (excluding GST): 24W at ₹2,500, 36W at ₹4,200. Minimum order quantity is 2 units. Custom wattages are available on request.
The right wattage depends on pole height, pole spacing, road width and the lighting level (lux) your project or municipality requires. Xera Tech's technical team provides lumen and lux calculations before purchase at no cost. Share your road width, pole height and spacing on WhatsApp +91-9607908430 or at connect@xeratech.in.
It carries ISO, BIS, NSIC, NABL, ZED, PWD, ERDA, GeM, NMC and is supplied to Municipal Bodies, NHAI, PWD, Industrial Estates, Smart City Corporations, Government Tenders, Commercial Projects. Compare your tender's technical specification with the datasheet and request certificates and test reports before bidding.
Step 1 – Fix the bracket: Secure the street light set bracket to the mounting surface (wall, pole, or structure) using M8 or M10 bolts. Ensure the surface can bear at least 20000g. Step 2 – Route the wiring: Route 3-core (L, N, E) cable rated for 90V – 300V AC through the conduit to the junction point. Minimum wire gauge: 1.5 mm². Step 3 – Connect terminals: Connect Live (L), Neutral (N) and Earth (E) to the corresponding terminals in the Isolated driver. The driver supports 90V – 300V AC at 50Hz. Step 4 – Mount the fixture: Attach the 36W–100W Street Light Set – Glass Model to the bracket, tighten the locking knob, and adjust the tilt angle for desired beam direction (120° beam). Step 5 – Test and verify: Power on via MCB/DP switch. Verify output brightness (CRI ≥ 80), check IP66 gaskets are sealed, and confirm 6kV surge protector LED is green. Use a qualified electrician and follow local electrical rules.
SL-GM-36-100 stands for Street Light, Glass Model, 36 W to 100 W. You can open this product directly at https://xeratech.in/products/SL-GM-36-100 or on its full page at https://xeratech.in/products/36w-100w-street-light-set-glass-model.
Yes. On this page, 'Watch live promo' plays a 40-second animated overview in English, Hindi or Marathi, with close-ups and the key specifications.

Customer Reviews

4.5
23 verified reviews
5
60%
4
25%
3
10%
2
3%
1
2%
P
Pradip Datir
✓ Verified

Excellent build quality, very bright. Installed 20 units on our campus road — functioning perfectly after 6 months. IP66 confirmed — no water ingress during heavy rains.

S
Supriya Shelar
✓ Verified

IP66 held up well during Pune monsoon. Good value for the price. The Down Choke design clearly runs cooler than our older back choke lights.

Similar Street Light Set Products

15% OFF
20W Street Light Set Glass Model – Xera Tech
20W Solar Street Light Set – Glass Model (External Battery Box)
₹14,500 ₹17,000
17% OFF
15W Street Light Set Glass Model – Xera Tech
15W Solar Street Light Set – Glass Model (Inbuilt Battery)
₹12,500 ₹15,000
16% OFF
36W Street Light Set Glass Model – Xera Tech
36W–100W Street Light Set – Glass Model
₹4,200 ₹5,000
18% OFF
24W Street Light Set Glass Model – Xera Tech
24W–30W Street Light Set – Glass Model
₹2,800 ₹3,400
17% OFF
9W Street Light Set Lens Model – Xera Tech
9W Solar Street Light Set – Lens Model (Inbuilt Battery)
₹7,500 ₹9,000
17% OFF
12W Street Light Set Lens Model – Xera Tech
12W Solar Street Light Set – Lens Model with RMS
₹9,500 ₹11,500

Recent Street Light Set Installations

Xera Tech has deployed 36W LED Street Light Set products across Maharashtra and pan-India — Nashik, Pune, Mumbai, Thane, Aurangabad, Kolhapur & more.

Dual Head Solar Street Light Setup at Dhone – Street Light Set installation by Xera Tech, Nashik Dhone
Dual Head Solar Street Light Setup at Dhone
Installed dual head 15W solar street lights along the roadside near Nehru Nagar in Dhone, opposite the Lord Venkateswara Swamy Temple. Each 6 meter GI tubular pole is fitted with an 80W solar panel and two 12Ah LiPo4 batteries, powering twin light heads that spread illumination across a wider stretch of the road. The layout gives even coverage along the pathway, supporting safer movement for pedestrians and vehicles passing through this developing area.
Solar
Solar Street Light in Thane – Street Light Set installation by Xera Tech, Nashik Shahapur
Solar Street Light in Thane
A solar street light was installed at Akhil Bharatiya Samaj Prabhodhan School, bhiwandi in Babare to provide reliable lighting around the premises. The installation enhances safety for students and staff while ensuring consistent illumination using clean solar energy.
Solar
Solar Street Lights at Mahad – Street Light Set installation by Xera Tech, Nashik Mahad
Solar Street Lights at Mahad
Xeratech's solar street lights successfully installed at Avani Enterprises, MG Road, Mahad Tq., Raigad. Providing eco-friendly, energy-efficient illumination to the area.
Solar Street Lights
Solar Street Light at Maharashtra – Street Light Set installation by Xera Tech, Nashik Nanavale
Solar Street Light at Maharashtra
Xeratech's Solar Street Lights offer eco-friendly, energy-efficient outdoor lighting powered by renewable solar energy, ensuring sustainability and cost savings.
Solar Street Lights
Solar street lights installation – Street Light Set installation by Xera Tech, Nashik Kolhapur
Solar street lights installation
Xeratech's Solar Street Light Installation at Kolhapur, Maharashtra Completed the installation of Xeratech tech with energy-efficient solar street lights in Kolhapur, Maharashtra. This project enhances public safety and reduces energy costs by utilising sustainable solar technology, providing reliable illumination for streets and public spaces throughout the city.
solar street light
Solar Street Light Project in Niphad – Street Light Set installation by Xera Tech, Nashik Niphad
Solar Street Light Project in Niphad
This solar street lighting project was completed in Niphad, Nashik to provide reliable illumination for village roads and surrounding public areas. The installation helps improve safety and visibility after sunset while reducing dependence on conventional electricity. Equipped with a high efficiency solar panel, lithium phosphate battery and a durable GI pole, the system delivers consistent performance with low maintenance, making it a sustainable lighting solution for rural communities.
Solar

Buy 36W LED Street Light Set from Nashik, India

Looking to buy 36W LED Street Light Set online in India? The 36W–100W Street Light Set – Glass Model is available at ₹4,200 (MRP ₹5,000) with pan-India delivery from our warehouse in Nashik, Maharashtra. Xera Tech is a MIDC-based LED lighting manufacturer supplying outdoor flood lights, street lights, high bay lights, and solar lights to government bodies, contractors, municipalities, factories and housing societies across India.

Our 36W Street Light Set range is available in wattages from 9W to 36W to suit every project scale. All models carry ISO, BIS, NSIC, NABL, ZED, PWD, ERDA, GeM, NMC certification and are pre-qualified for government tenders.

For bulk pricing, project quotations, or dealer/distributor inquiries for Street Light Set in Nashik, Maharashtra, or pan-India — call +91-9607908423 or email connect@xeratech.in. Our technical team provides pre-purchase consultation, lumen calculations, and project-specific recommendations at no cost.
