Download complete technical datasheet including wattage, dimensions, IP rating, material specifications, lumen output, installation details and warranty information.
12W Solar Street Light Set – Lens Model (Inbuilt Battery)
SSL-LM-12-INB IP65 120° CRI ≥ 80
Short link:
xeratech.in/products/SSL-LM-12-INB
Excl. GST | Min. 2 units | In stock: 200 units
Min. 2 units
Key Highlights
Why Choose the 12W Street Light Set
Solar Savings Calculator
A 12W Street Light Set runs on solar power, so it adds nothing to your electricity bill. See what a grid-fed light of the same wattage would cost you each year: that is the grid electricity you avoid with solar.
Glass Model vs Lens Model – Key Differences
| Feature | Glass Model | Lens Model This Model |
|---|---|---|
| Cover Material | Toughened borosilicate glass | Polycarbonate / PMMA lens |
| UV Resistance | ✓ Excellent — no yellowing or fogging over time | Good, but may degrade slightly over 5+ years |
| Chemical Resistance | ✓ Superior — resistant to acids, solvents, industrial fumes | Moderate resistance |
| Light Transmission | ~92% (flat even distribution) | ~94% (precise beam shaping) |
| Impact Resistance | High (toughened glass) | Higher (polycarbonate is flexible) |
| Best For | Industrial, chemical plants, outdoor roads, solar systems, long-term installs | Sports courts, accent/display lighting, precise angle requirements |
| Maintenance | Easy to clean, no static charge | Lens may attract dust via static |
Product Description
The 12W Solar Street Light Set – Lens Model (Inbuilt Battery) is a 12W LED Street Light Set manufactured by Xera Tech in Nashik, Maharashtra. Designed for demanding outdoor and industrial environments, this IP65 street light set features a polycarbonate lens for precise beam shaping — making it one of the most durable outdoor street light sets available in India.
Powered by 90% efficient LEDs with a rated life of 50,000 hr, this 12W outdoor street light set delivers a 120° beam angle and CRI of ≥ 80 — ensuring excellent colour rendering for streets, villages, campuses and public spaces. The Aluminium Die Cast LED Head housing provides structural rigidity and efficient heat sinking, critical for continuous-duty outdoor installations.
Operating on a 12V DC (Battery Operated) system with built-in 6kV surge protection, this IP65 street light set runs on solar power with no grid connection or electricity bill, so it can light roads and villages where grid supply is unreliable or unavailable. Operating temperature range: -20°C to 50°C.
Certified ISO, NSIC, NABL, ZED, PWD, ERDA, GeM, NMC, the 12W Solar Street Light Set – Lens Model (Inbuilt Battery) is pre-qualified for government tenders, municipal infrastructure bids, and private industrial procurement across India. Applications include: Residential Colony Roads, Society Pathways, Service Lanes, Gram Panchayat Streets, Off-Grid Village Lighting, Campus Roads.
As a leading LED street light set manufacturer in Nashik, Maharashtra, Xera Tech supplies this product pan-India with 2 Years manufacturer warranty and 7 days return policy (HSN: 9405 49 00). The Isolated driver also carries a 2 Years warranty, ensuring your total cost of ownership remains predictable over the fixture's lifetime.
Full Technical Specifications
| Brand | Xera Tech |
|---|---|
| SKU / Model | SSL-LM-12-INB |
| Wattage | 12W |
| LED Efficiency | 90% |
| LED Life | 50,000 hr |
| CRI | ≥ 80 |
| Beam Angle | 120° |
| IP Rating | IP65 |
| Housing | Aluminium Die Cast LED Head |
| Driver Type | Isolated |
| Driver Efficiency | 90% |
| Voltage Range | 12V DC (Battery Operated) |
| Surge Protection | 6kV |
| Operating Temp. | -20°C to 50°C |
| Dimensions (H×W×D) | 6000mm × 300mm × 300mm |
| Package Dims. | 6200mm × 350mm × 350mm |
| Weight | 13,000g |
| Mounting Pipe ID | 76mm |
| Body Colour | Customisable (PU Paint) |
| Colour Variants | Cool White,Natural White,Warm White |
| Warranty | 2 Years |
| Driver Life | 2 Years |
| Application | Residential Colony Roads, Society Pathways, Service Lanes, Gram Panchayat Streets, Off-Grid Village Lighting, Campus Roads |
| Certifications | ISO, NSIC, NABL, ZED, PWD, ERDA, GeM, NMC |
| Customer Segment | Gram Panchayats, Municipal Bodies, Housing Societies, Real Estate Developers, Government Solar Tenders, Rural Electrification Projects |
| Min. Order Qty | 2 units |
| HSN Code | 9405 49 00 |
| Return Policy | 7 days |
Key Features
Certifications
Applications
How to Install the 12W Solar Street Light Set – Lens Model (Inbuilt Battery)
Complete installation guide for the 12W Street Light Set (Lens Model, Solar Lens Model). Required supplies: 12W LED Lens Model Luminaire with Inbuilt Battery (1 No), Mono Solar Panel (1 No), MPPT Controller (Inbuilt), 6 Mtr GI Pole, Customisable Bracket, Base Plate (Optional), Foundation Bolts (Optional), Junction Box, Mounting Hardware.
Frequently Asked Questions about 12W LED Street Light Set
Customer Reviews
Excellent build quality, very bright. Installed 20 units on our campus road — functioning perfectly after 6 months. IP66 confirmed — no water ingress during heavy rains.
IP66 held up well during Pune monsoon. Good value for the price. The Down Choke design clearly runs cooler than our older back choke lights.
Similar Street Light Set Products
Recent Street Light Set Installations
Xera Tech has deployed 12W LED Street Light Set products across Maharashtra and pan-India — Nashik, Pune, Mumbai, Thane, Aurangabad, Kolhapur & more.
Dhone
Shahapur
Mahad
Nanavale
Kolhapur
Niphad
Buy 12W LED Street Light Set from Nashik, India
Looking to buy 12W LED Street Light Set online in India? The 12W Solar Street Light Set – Lens Model (Inbuilt Battery) is available at ₹8,500 (MRP ₹10,500) with pan-India delivery from our warehouse in Nashik, Maharashtra. Xera Tech is a MIDC-based LED lighting manufacturer supplying outdoor flood lights, street lights, high bay lights, and solar lights to government bodies, contractors, municipalities, factories and housing societies across India.
Our 12W Street Light Set range is available in Glass Model and Lens Model cover options; wattages from 9W to 36W to suit every project scale. All models carry ISO, NSIC, NABL, ZED, PWD, ERDA, GeM, NMC certification and are pre-qualified for government tenders.
For bulk pricing, project quotations, or dealer/distributor inquiries for Street Light Set in Nashik, Maharashtra, or pan-India — call +91-9607908423 or email connect@xeratech.in. Our technical team provides pre-purchase consultation, lumen calculations, and project-specific recommendations at no cost.
