Solar Street Light Battery Replacement - When and How to Do It

Q: How often does a solar street light battery need replacement?

LiFePO4 battery: every 7–10 years. Lead-acid battery: every 2–3 years. These are averages - actual life depends on depth of discharge, temperature, and quality of the charge controller.

Q: Can I upgrade my old lead-acid solar light to LiFePO4?

Yes, but you must also replace the charge controller (the charging profile is different). Xera Tech supplies LiFePO4 upgrade kits including a compatible MPPT controller for common solar light models. Contact the service team for compatibility verification.

Q: Where can I buy a replacement LiFePO4 battery for a solar street light in Nashik?

Xera Tech supplies replacement LiFePO4 batteries for their own products and for other common models. Visit the Nashik facility at Satpur MIDC or contact connect@xeratech.in with your battery voltage, capacity (Ah), and physical dimensions.

Solar Street Light Battery Replacement - When and How to Do It

Battery degradation is the most common reason solar street lights start underperforming after 3–5 years. Replacing the battery at the right time - with the right specification - restores full performance and extends the system life by another 5–7 years.

By Xera Tech Team · Updated June 1, 2025 · 4 sections

Signs the Battery Needs Replacement

The light fails to stay on the full night even after several consecutive sunny days. The light is significantly dimmer than it was originally. Charging time has increased (the battery takes longer to reach full charge). The light does not work at all after the controller's protection has been bypassed. Visible physical damage: swelling (lead-acid), leaking electrolyte, or burn marks on the battery casing. For LiFePO4 batteries, use a battery tester or BMS readout to check State of Health (SoH) - below 70% SoH indicates replacement is due.

Choosing the Right Replacement Battery

Always match: battery chemistry (LiFePO4 for LiFePO4 systems, do not substitute). Voltage (typically 12.8V for 12V systems, 25.6V for 24V systems). Capacity in Ah and Wh (same or higher capacity is fine, do not reduce). Physical dimensions (must fit the existing battery compartment or box). BMS voltage protection range (must match the existing charge controller settings). Using an incompatible battery chemistry without changing the charge controller will damage the battery or create a fire risk.

Step-by-Step Replacement Procedure

Step 1: Cover the solar panel with a cloth to prevent the system from operating during work. Step 2: Open the battery compartment or remove the fixture (for all-in-one models). Step 3: Note all wiring connections - photograph before disconnecting. Step 4: Disconnect the battery, negative terminal first (red/positive last). Step 5: Remove the old battery. Dispose of lead-acid batteries at an authorised recycler - they contain hazardous material. LiFePO4 can be recycled at lithium battery recycling centres. Step 6: Install new battery with the same polarity. Connect positive first, negative last. Step 7: Check all connections are tight. Close the compartment. Step 8: Uncover the panel and test operation.

Frequently Asked Questions

How often does a solar street light battery need replacement?

Can I upgrade my old lead-acid solar light to LiFePO4?

Where can I buy a replacement LiFePO4 battery for a solar street light in Nashik?
