The Height-Lux Relationship

The inverse square law governs lighting: if you double the mounting height, the lux at floor level falls to one quarter. Practically: a 100W highbay at 6m height produces ~200 lux at the floor. The same light at 8m height produces ~115 lux. At 10m height: ~73 lux. This means going from 6m to 10m ceiling requires 2.7× more fixtures (or 2.7× higher wattage) for the same lux level - a very significant cost and energy difference. Always specify the exact ceiling height before selecting highbay wattage.

Optimal Installation Heights by Wattage

50W UFO highbay: 4–6m ceiling (produces 200 lux at 5m height on 4m × 4m grid). 100W UFO highbay: 6–9m ceiling (produces 200 lux at 7m height on 5m × 5m grid). 150W UFO highbay: 8–12m ceiling (produces 200 lux at 10m height on 5m × 5m grid). 200W UFO highbay: 10–14m ceiling. 250W UFO highbay: 12–16m ceiling. 300W linear highbay: 10–18m ceiling (best for long aisles). Always verify with a photometric calculation using the actual fixture's IES (photometric data) file.

Beam Angle Selection for Height

UFO highbay lights come in different beam angles: 60° beam: for tall ceilings (10m+) where concentrated downward projection is needed - narrow pool of light directly below. 90° beam: most common for 6–10m ceilings - good balance of intensity and coverage. 120° beam: for lower ceilings (4–6m) - wider spread, lower peak intensity. For warehouses with racking: use 60° or 90° lights mounted above each aisle for focused aisle lighting. For open factory floors without racking: use 120° for even coverage between fixtures.

Suspension vs Direct Mount

Direct mount (surface mounting to structural beam): simplest, no adjustment possible. Pendant mount with chain or wire rope: allows height adjustment - hang the light at the optimal height even if the structural ceiling is higher. This is ideal for old industrial buildings with very high ceilings where you do not want to mount at ceiling height but rather at 8m in a 14m building. Hook mount: quick installation, suitable for temporary or frequently reconfigured facilities. For clean rooms and food processing plants: use enclosed, sealed fixtures in a direct surface-mount configuration to prevent contamination.
